Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment

Name: Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment
Brand: XioFiTec/Hanyan
Price: 100 USD

China Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment wholesale

Certification : CE/CCC/ISO9001

Packaging Details : Wooden Box

Supply Ability : 100 Set/Sets per Month

Price : 100

Brand Name : XioFiTec/Hanyan

Model Number : XioFiTec/Hanyan

condition : New

machine type : Welding Manipulator

place of origin : Sichuan, China

brand name : Hanyan Technology

warranty : 1 Year

weight (kg) : 200

voltage : 200(control) / 380(weld)

current : 500A(Max.) for welding

rated capacity : According to welding source

rated duty cycle : over 60%(200A); within 60%(250A)

dimensions : 1900*600*1700mm

usage : circumferential seam welding

After-sales Service Provided : Field installation, commissioning and training

equipment : welding equipment

Workpiece length : 0-1200mm

Workpiece diameter : 0-200mm

Rotating diameter : 550mm

Welding speed : 1-10RPM

Service : Customer driven solution

Parameters : Refer to details

Weight : 200Kg

Applicable Industries : Manufacturing Plant

Showroom Location : Egypt, Turkey, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Ordinary Product

Warranty of core components : 1 Year

Core Components : PLC, Bearing, Gearbox, motor, Gear

Key Selling Points : Automatic

Port : Shanghai/Chongqing

Contact Now

Customization

WE CAN ENGINEER ANY MODEL TO AUTOMATE YOUR CUSTOM APPLICATION, AND SPECIALIZE IN PROVIDING A CUSTOMER DRIVEN SOLUTION TO YOUR WELDING NEEDS!

we already have clients from US,VN,PL,RU,IN,ZA,UZ,CS, BR,ZE,AE etc. include A.O. smith. We can offer you the best products.

Product Description

Application:

Easy to build an circumferential seam automatic welding system with welding source torche, to improve welding speed and quality.

Components:

It mainly consists of rotation headstock, tailstock, lathe bed, 3-D adjusting mechanism, pneumatic lifter and PLC controlling system. Combined structure is convenient for installation, and has a good mobility.

Lathe Bed: With guide rail, and the distance between headstock and tailstock is adjustable.

Rotation Headstock: Driven by DC gear motor, has stepless speed regulation function and welding current detection switch.

Tailstock: Operate hand whell, and impart motion to center.

Adjustable 3-D Device: Adjust torch position accurately.

Pneumatic Lifter: Lift up torch automatically.

Control System: Advanced PLC controlling system, humanized operation interface, high degree automation, stable and reliable performance.

technical parameters

Model	HF-300W
Control power supply	Single phase 50Hz AC 200V
Welding power supply	Three phase 50Hz AC 380V
Workpiece thickness	According to the shape of opening
Workpiece diameter	200 mm≥φ≥10mm
Workpiece length	≤1200mm
Headstock rotation speed	1~10 r/ min
Workpiece rotating diameter	≤550mm
Spindle bore	φ≤50mm
Spindle output torque	≤72N·m
Workpiece weight	≤50Kg
Torch lifting height	100mm(pneumatic)
Tailstock travel stock	150mm(pneumatic)
Headstock adjustable angle	0°,30°,45°,60°,90°
Torch 3-D adjustable range	X:±30mm, Y:±50mm, Z:±30mm
Max. welding current	500A

Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment

Other Standard Welding Machinery:

1. circumferentinal seam welding:

1.1. Horizontal:

HF-300W: singel seam welding

HF-300WS: double seam welding

1.2. Vertical:

HF-300L: single seam welding

HF-300LY: pressing and welding

2. longitudinal seam welding(ZF-Series):

ZF-500: 500mm

ZF-1000: 1000mm

ZF-1500: 1500mm

ZF-2000: 2000mm

ZF-2500: 2500mm

ZF-3000: 3000mm

Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment

Chengdu Hanyan Technology Co., Ltd.

is a national high-tech enterprise who specializing in designing, researching and developing, manufacturing and serving of automatic welding equipment. wholly-owned three sub-companies, covering resistance welding, robot welding and welding power source.

From now on, we obtained 5 Patents of invention and 13 Patents of Utility Model; our products are approved by CCC and CE, additionally, our company have had ISO 9001:2008, ERR and CRM management system.
We exported to over 29 countries and regions including General Longitudinal/Circumferential Seam Welder, Welding Auxiliaries, Water Heater Welding Line, Fuel Tank Welding Line, Welding Robots, Strip Welding Equipment, Resistance Welding Equipment, Welding Power Sources and other Customized Welding Equipment.

WE CAN ENGINEER ANY MODEL TO AUTOMATE YOUR CUSTOM APPLICATION, AND SPECIALIZED IN PROVIDING A CUSTOMER DRIVEN SOLUTION TO YOUR AUTOMATED WELDING NEEDS!

Packaging & Shipping

Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment

Visit

In user factory:

1. Before sales: on site techinical solution and quotation.

2. after sales: installation, commisionning, training.

Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment

In our factory:

Precision And Smooth Circumferential Welder Horizontal Automated Welding Equipment

About us

Chengdu Hanyan Technology Co., LTD. is a national high-tech enterprise specializing in designing, researching and developing, manufacturing and serving of automatic welding equipment.

With 360 employees, including 159 who have been devoting into welding area for over 15 years, we are serving customers worldwide with dozens of various types of precision equipment and a factory covering an area of 15000sqm. To establish modern management, we customized an ERP system which could ensure punctual delivery and offer process surveillance. We have accomplished more than 20 patents in automatic welding industry. We are capable of providing 4000 units specialized welding equipment annually.
